Schneider Electric Off/On Switch
In Stock
Benefits Of Schneider XB4BD Series Push Button Switch
- High performance even in the most demanding environments
- Attractive design, reinforced with the flush mounting kit
- Flexibility and adaptability through modular design
- Simplicity and speed of installation
- Wide offer providing a solution for all your applications
- Delivering: We offer Nationwide Delivery - Monday - Saturday
- Call: +2348063316412
- Customer Care: We offer technical support and after sales service
- Address: Shop F464 F-Line Industrial Section, Alaba International Market, Ojo, Lagos State, Nigeria.
Description
Schneider Electric Off/On Switch
Schneider XB4BD Series Push Button Light Switch / Industrial Push Button On Off Switch
| Type: | XB4BD Push Button | Product Or Component Type: | Selector Switch |
|---|---|---|---|
| Mounting Diameter: | 22 Mm | Colour: | Red Orange Green White |
| Operator Profile: | Black Standard Handle | Product Weight: | 0.095 Kg |
| High Light: |
push on push off switch, momentary push button switch, XB4BD Series Push Button Switch |
||
Schneider XB4BD Series Push Button Electrical Switch Industrial Push-button Press button Switch
Benefits Of Schneider XB4BD Series Push Button Switch
- High performance even in the most demanding environments
- Attractive design, reinforced with the flush mounting kit
- Flexibility and adaptability through modular design
- Simplicity and speed of installation
- Wide offer providing a solution for all your applications
Datasheet Of Schneider XB4BD Series Push Button Electrical Switch XB4BD21
| device short name |
XB4
|
|
|---|---|---|
| bezel material |
Chromium plated metal
|
|
| fixing collar material |
Zamak
|
|
| mounting diameter |
22 mm
|
|
| sale per indivisible quantity |
1
|
|
| head type |
Standard
|
|
| shape of signaling unit head |
Round
|
|
| type of operator |
Stay put
|
|
| operator profile |
Black standard handle
|
|
| operator position information |
2 positions 90°
|
|
| contacts type and composition |
1 NO
|
|
| contact operation |
Slow-break
|
|
| connections – terminals |
Screw clamp terminals : <= 2 x 1.5 mm² with cable end conforming to EN/IEC 60947-1
Screw clamp terminals : >= 1 x 0.22 mm² without cable end conforming to EN/IEC 60947-1 |
| height |
47 mm
|
|
|---|---|---|
| width |
30 mm
|
|
| depth |
68 mm
|
|
| terminals description ISO n°1 |
(13-14)NO
|
|
| product weight |
0.095 kg
|
|
| resistance to high pressure washer |
7000000 Pa at 55 °C,distance: 0.1 m
|
|
| contacts usage |
Standard contacts
|
|
| positive opening |
Without positive opening
|
|
| torque value |
0.14 N.m (NO changing electrical state)
|
|
| mechanical durability |
1000000 cycles
|
|
| tightening torque |
0.8…1.2 N.m conforming to EN 60947-1
|
|
| shape of screw head |
Cross head compatible with Philips no 1 screwdriver
Cross head compatible with pozidriv No 1 screwdriver Slotted head compatible with flat Ø 4 mm screwdriver Slotted head compatible with flat Ø 5.5 mm screwdriver |
|
| contacts material |
Silver alloy (Ag/Ni)
|
